Piet ceiling panel
The Piet Ceiling Panel System by Impact Acoustic redefines overhead design with a bold, architectural approach to acoustic performance. Inspired by geometric abstraction, Piet uses a grid of three tile formats -Small, Medium, and Large-arranged in 1200 × 1200 mm clusters with precise 50 mm spacing. The result is a dynamic, pattern-rich ceiling that absorbs sound while adding rhythm and structure.
Crafted from ARCHISONIC® Felt with 60% post-consumer recycled PET, the 24 mm thick panels achieve excellent acoustic results with NRC 0.85 (ASTM) and αw 0.75 (EN ISO 11654) when suspended with a 200 mm airgap. The modular system installs easily using steel strut profiles and patented FeltFix mounts, allowing on-site adjustments and full design flexibility; including customizable gaps, three tile corner styles (Straight, Fillet, Chamfer), and up to three color variations per layout.
Backed by a 10-year warranty, Piet delivers design precision, circularity, and acoustic performance. Ideal for offices, public buildings, hospitality, and cultural spaces seeking bold ceiling statements with functional impact.
• Tile spacing: 50mm (1.96”)
• Cluster spacing: 50mm (1.96”)
• Material thickness: 24mm (0.94”)
• Tile clusters:
- Outer dimensions: 1200mm x 1200mm (47.25” x 47.25”)
- Gaps between tiles: 50mm (1.96”)
• Base tile sizes:
- Small: 575mm x 575mm (22.6” x 22.6”)
- Medium: 575mm x 1200mm (22.6” x 47.25”)
- Large: 1200mm x 1200mm (47.25” x 47.25”)
• Tiles: 100% PET (60% post-consumer content)
• Spring frame profiles: Steel (galvanized or powder-coated black)
• ISO tests:
- αw: 0.75
• ASTM Tests:
- NRC: 0,85
• Acoustic performance (αp) by frequency:
- 125Hz: 0.05
- 250 Hz: 0.45
- 500 Hz: 0.85
- 1000 Hz: 1.00
- 2000Hz: 1.00
- 4000 Hz: 1.00
•Standards:
- ISO 354: Sound absorption measurement
- ISO 11654: Sound Absorber Classification
- ISO 20189: Acoustic classification for interior elements
- ASTM C423-17: Sound Absorption Test
- ASTM E795-16: Sound Absorption Test Methods
• Daily cleaning: Alcohol solution (75%) (e.g. Pantasept)
• Dust removal: Feather duster or vacuum cleaner
• Heavy soil: Hydrogen peroxide treatment
• DIN EN 13501-1: B-s1, d0
• ASTM E84: Class A
• VOC emissions:
- 28 days of French regulation: A+
- BREEAM® (International, UK, NL, SE, NOR): Exemplary.
- CDPH Standard V1.2: Succeed.
•Certifications:
- Label declaration, Cradle to Cradle, UL Environmental Product Declaration.
- Member of the US Green Building Council, Ecobau 1st Priority, Climate-KIC.
- VOC emissions that comply with the LEED EQ credit (low emission products).
- SCS recycled content.
