Pinstripe Wood Wool Ceiling
BAUX Pinstripe Wood Wool Ceiling panels put a fine, even line across a suspended ceiling. The grooves are narrow enough to read as texture rather than pattern, so the ceiling stays calm while the light picks out a subtle direction across the room. The 25 mm panel comes in two versions: 600 x 1200 mm for a concealed grid, where the joints all but disappear, and 593 x 1193 mm for a standard exposed grid.
The panels are made from Swedish fir wood wool bound with cement and water. The material is FSC and PEFC certified, Red List Free, and documented with an EPD and Health Product Declaration. It carries fire reaction class B-s1, d0 and contributes to BREEAM and LEED credits.
With 40 standard colours and custom colours on request, the Pinstripe ceiling panel suits offices, classrooms, hospitality and public buildings that need reverberation brought down across a large ceiling without a heavy visual footprint. It installs in a ceiling grid or on wooden battens, and pairs with the Flat panel where you want the stripe to stop.
• Pinstripe Concealed Grid
Width: 600 mm, 24"
Height: 1200 mm, 48"
Thickness: 25 mm, 1.0″
Pieces per m2 and q.ft.: 1.39/m2, 0.129/sq.ft.
• Pinstripe Exposed Grid
Width: 593 mm, 23.8"
Height: 1193 mm, 47.8"
Thickness: 25 mm, 1.0″
Pieces per m2 and q.ft.: 1.39/m2, 0.129/sq.ft.
'- Portland cement
CAS: 65997-15-1 (44%)
- Wood Swedish fir (37%)
- Water (10%)
- Limestone powder
CAS: 471-34-1 (9%)
- Paint, water based <1% (if coloured)
• Forest Stewardship Council
The Wood Wool used in BAUX products is always FSC-certified. FSC’s pioneering certification system enables businesses and consumers to choose wood, paper and other forest products made with materials that support responsible forestry.
• Environmental Product Declaration
BAUX Acoustic Wood Wool has undergone a complete and certified EPD testing, providing transparent environmental impact estimates cross the product life cycle, from raw material to end of use.
• Declare Label
BAUX products are compliant to Declare Label and are therefore Red List Free and sourced with responsibility. Declare is a nutrition label for building products. It is designed to help specifiers quickly identify products that meet their project requirements.
• Red List Free
BAUX Acoustic Wood Wool does not contain any harmful chemicals and is approved to be free from Red Listed ingredients. Products with this label comply with the Living Building Challenge goals of ingredient transparency and industry-wide elimination of Red List chemicals.
• Health Product Declaration
BAUX Health Product Declaration transparently details the contents of the product. An HPD is a standardised report of a product’s contents and associated health information, following the HPD Open Standard.
• Indoor Emissions
BAUX Acoustic Wood Wool offers superior indoor quality and is approved for several other emission standards. This measure inspires the use of low-emission construction materials, and the responsibility corresponds to the manufacturer of the product.
• Programme for the Endorsement of Forest Certification
The Wood Wool used in BAUX product is PEFC certified. An independent, not-for-profit organisation promoting sustainable forest management through the certification of forests and the products that come from them.
• Building Research Establishment Environmental Assessment Methodology
BAUX Acoustic Wood Wool contributes positively to Breeam certification of buildings. Breeam is the oldest method of assessing, rating and certifying a building’s environmental sustainability.
• LEED V.4
BAUX Acoustic Wood Wool contributes positively to LEED-certification of buildings. LEED v4 is designed to up the ante with a more flexible, performance-based approach that calls for measurable results throughout a building’s life cycle.
• California Department of Public Health
BAUX Acoustic Pulp deliver superior indoor quality and is qualified according to CDPH. CDPH’s goal is to improve health and well-being by issuing various authorisations to regulate professionals, facilities, and equipment.
